automatic stand up slant corner spout nozzle pouch packing machine
Looking for a sippy bag filling machine? Or looking for a stand-up pouch packaging machine? Whether you are looking for bag packing or bag filling, we can do it all!
Mechanical filling equipment for filling liquid, paste, powder, granule and other substances into bags, sealing bags, stand-up pouches, suction nozzle bags, pre-made bags.
The equipment is widely used for: juice drink bag filling, laundry detergent filling, toiletries filling, red wine boxed bag filling, with suction nozzle jelly filling, baby food puree filling, soya bean milk filling, etc.
Paste: syrup health care products filling, plasma metering filling, etc.
In order to improve the production efficiency, ensure the filling accuracy and product quality, we can not only bag filling, but also through the metering system for accurate measurement of the material weighing, after the completion of the filling, the bag sealing and capping process, to ensure that the bag sealing and equal amount.
Product parameters:
| Filling precision: | ±1% |
|---|---|
| Filling speed: | 30～60 bag /minute |
| Capping speed: | 30～60 pieces/minute |
| Labeling accuracy: | ±1mm |
| Blowing speed: | 30～60 bags/minute |
| Label roll inner diameter： | Φ76mm |
| Maximum outer diameter ： | Φ280mm |
| Applicable length: | 20-200MM |
| Machine size (L*W*H) ： | 1200*1770*940(mm) |
| Power supply ： | 220V/50HZ |
| Machine weight： | 180KG |
| Minimum order quantity: | one unit |
| Shipping Port ： | Guangzhou/shenzhen |
| Payment Method： | 50% deposit and 50% after acceptance |
| Delivery Capacity ： | 20-35pcs/min |
| Delivery Time： | ≧15 working days |
| Packing Information： | All packed in wooden crates |
Working Principle：
Automatic standing angled nozzle sachet packaging machine is highly automatized as well as integrated system. The following is a detailed description of its main functions:
Automatic bag feeding:
The filling station is fitted with an automatic bag feeder that feeds stand-up bevelled nozzle sachets already made. This makes sure that pouches are available all the time reducing on idle time and boosting production.
Rotary Filling:
After they are inserted onto the specified positions, the pouches move to the rotary fill point. It employs precision filling nozzles to spray the liquid product into the pouches through the cooking process. The rotary design also enables filling of several pouches simultaneously, thus increasing the production rate.
Automatic Capping and Sealing:
On filling, the pouches transist to the capping and sealing section. Here the lid of the bottle opening is set to close automatically and seal the bottle to avoid a leakage. It employs high technology in capping to ensure that it produces the right torque that will not allow any droppage or leakages on transit.
Conveyor System:
The whole process is then terminated by a conveying mechanism which moves the pouches from one working station to another. In this way the process is fast and contains little human interference eliminating the chance for contamination.
Product advantages
High efficiency:
A major advantage of the machine is that its operation largely minimizes time needed for packaging, meaning more packages with less people.
Accurate filling:
Rotary filling station also enhances the efficiency of filling process such that each pouch reaches the correct measure without spilling and wasting the product.
Hygiene and Safety:
To ensure the best hygiene, the machine is made out of food grade materials in its construction. This makes sure that packaged product get to the supermarket without getting contaminated or affecting other products.
Versatility:
The machine can be adjusted to cover many liquid products such as drinks, sauce, and washing solutions among others. The above advantage makes it to be suitable for companies with various products that they can package in the same material.
Cost-effective:
Even though the initiation cost is considerably high, the machine is less expensive than employing workers since it operates at a faster pace, doesn’t waste materials and time.
Application Fields:
[row_inner_3] [col_inner_3 span__sm=”12″]Food industry:
for packaging of soya milk, fruit juice, milk, yoghurt, beverage, honey, flour, sugar, coffee, seasoning and other products.
Chemical industry:
suitable for accurate packaging of fertilisers, pesticides and other chemical products.
Pharmaceutical industry:
for safe filling of pharmaceutical powders and liquids.
Daily chemical industry:
for detergent, shampoo, shower gel, laundry detergent, hand soap, shower gel .
[/col_inner_3] [/row_inner_3]Ideal markets：
White wine vat filling
Bird’s nest bottle
Fruit juice
Honey
Soy sauce
Mineral water
Case Video：
FAQ:
This machine is suitable for packing all kinds of liquid, paste, cream, powder and other products.
The machine uses precise filling nozzles and a rotary filling station to ensure consistent, accurate filling of each pouch.
The machine is designed for easy maintenance and troubleshooting. Regular cleaning and lubrication of moving parts as well as periodic inspections help extend the life of the machine and maintain optimum performance.
Yes, the machine can be customised to meet specific packaging needs, including nozzle pouch filling, pouch size, spout design and capping mechanism.
Depending on the machine model and configuration, production speeds can range from 30 to 500 pouches per minute, suitable for medium to large scale production requirements, with customisation available for higher requirements.
